P6
Hangel
HTF-ROD6-576AL
Availability: | |
---|---|
Special Designed Aluminum Cabinet, Lighter, Thinner & More Accurate
The cabinet is special designed die casting aluminum cabinet, with thinner body, lighter weight. The depth of the cabinet is only 80mm, and the weight is only about 10KG/pc.
Considering the cabinet is die casting made, the size is much more accurate to assemble a seamless, perfect whole screen, even for very thin pixels, such as 1.5mm, 2mm, 2.5mm, even thinner.
Water Proof & High Brightness for Outdoor Use
The screen is made as IP65, water proof & dust proof, and with the high brightness of over 6000 cd/sqm. All of these make sure the screen can perform well for outdoor using, even facing the sun.
Fast Lock, Dowel Pin Lock, Strengthen Rib, Easy Assembling & Dismantling
The light cabinet with fast lock & dowel pin lock & flight case packing ensure the screen assembling & dismantling & packing & removing easy. One person is capable to do the job. The cabinet is born for rental market.
High Quality LEDs
SMD2121 black LED (from National Star, gold line encapsulated ), RGB 3 in 1 pixel, high contract ratio, wide viewing angle, horizontal & vertical both 140 degree. Viewers can get vivid image at a wider scale
Exquisite & Vivid Image
The display can play 10-bit colors, with 65536 levels gray scale, high refresh rate over 3000 HZ, high contrast ratio to play natural, vivid & exquisite image. The display will bring outstanding visual feast for viewers.
Application
> Stage Background
> Various Trade Show, Exposition, Exhibition
> Official Meetings
> Kinds of Celebration Ceremony, Opening Ceremony
> Wedding, playing image promo, concerning ads, etc.
> Some Banquets, Concerts
> Summit Forum, Press Conference
> Other Events, Campaigns, etc. visual feast to viewers.
Special Designed Aluminum Cabinet, Lighter, Thinner & More Accurate
The cabinet is special designed die casting aluminum cabinet, with thinner body, lighter weight. The depth of the cabinet is only 80mm, and the weight is only about 10KG/pc.
Considering the cabinet is die casting made, the size is much more accurate to assemble a seamless, perfect whole screen, even for very thin pixels, such as 1.5mm, 2mm, 2.5mm, even thinner.
Water Proof & High Brightness for Outdoor Use
The screen is made as IP65, water proof & dust proof, and with the high brightness of over 6000 cd/sqm. All of these make sure the screen can perform well for outdoor using, even facing the sun.
Fast Lock, Dowel Pin Lock, Strengthen Rib, Easy Assembling & Dismantling
The light cabinet with fast lock & dowel pin lock & flight case packing ensure the screen assembling & dismantling & packing & removing easy. One person is capable to do the job. The cabinet is born for rental market.
High Quality LEDs
SMD2121 black LED (from National Star, gold line encapsulated ), RGB 3 in 1 pixel, high contract ratio, wide viewing angle, horizontal & vertical both 140 degree. Viewers can get vivid image at a wider scale
Exquisite & Vivid Image
The display can play 10-bit colors, with 65536 levels gray scale, high refresh rate over 3000 HZ, high contrast ratio to play natural, vivid & exquisite image. The display will bring outstanding visual feast for viewers.
Application
> Stage Background
> Various Trade Show, Exposition, Exhibition
> Official Meetings
> Kinds of Celebration Ceremony, Opening Ceremony
> Wedding, playing image promo, concerning ads, etc.
> Some Banquets, Concerts
> Summit Forum, Press Conference
> Other Events, Campaigns, etc. visual feast to viewers.
Model No. | HTF-ROD6 SMD |
Pixel Pitch | 6mm |
Pixel Density | 27,778 dots/sqm |
LED Tech | SMD3535, RGB 3 in 1 |
Module Size | 192 x 192mm |
Module Resolution | 32 x 32 pixels |
Cabinet Size | 576 x 576 x 80mm |
Cabinet Frame | Lifting Cabinet |
Cabinet Material | Die Casting Aluminum |
Cabinet Resolution | 96 x 96 pixels |
Cabinet Weight | 12 KG/pc |
Brightness | >6000 nits (cd/sqm), bright enough for outdoor facing sunlight |
Brightness Controlling | Manual 256 levels, Auto 8 level |
Driving Mode | 1/8 scan, constant current driving |
Refresh Rate | >1000 HZ |
Frame Rate | 60 HZ |
Grey Scale | 65536 level |
Display Colors | 10-bit colors |
Viewing Distance | 3 ~ 300 meters |
Viewing Angle | Hor. 160; Ver. 160 |
Protection Grade | Front IP65; Back IP54, weather proof |
Power Input | AC110V 60HZ / AC220V 50HZ, 10% more or less |
Power Consumption | Max.1200w/sqm Aver. 400w/sqm |
Working Temp. | -30 Celsius ~ +50 Celsius |
Working Humi. | 10% ~ 90% |
Maintenance | Rear access, replace fault components |
Signal Input | AV, S-Video, VGA, DVI, HDMI, SDI, DP (use Video Processor) |
Controlling Distance | CATE 5 < 100 mts; SMF < 10 KM; 3G, 4G controlling no distance limitation |
MTBF | > 5000 Hours |
LED Life Span | 100,000 Hours |
Model No. | HTF-ROD6 SMD |
Pixel Pitch | 6mm |
Pixel Density | 27,778 dots/sqm |
LED Tech | SMD3535, RGB 3 in 1 |
Module Size | 192 x 192mm |
Module Resolution | 32 x 32 pixels |
Cabinet Size | 576 x 576 x 80mm |
Cabinet Frame | Lifting Cabinet |
Cabinet Material | Die Casting Aluminum |
Cabinet Resolution | 96 x 96 pixels |
Cabinet Weight | 12 KG/pc |
Brightness | >6000 nits (cd/sqm), bright enough for outdoor facing sunlight |
Brightness Controlling | Manual 256 levels, Auto 8 level |
Driving Mode | 1/8 scan, constant current driving |
Refresh Rate | >1000 HZ |
Frame Rate | 60 HZ |
Grey Scale | 65536 level |
Display Colors | 10-bit colors |
Viewing Distance | 3 ~ 300 meters |
Viewing Angle | Hor. 160; Ver. 160 |
Protection Grade | Front IP65; Back IP54, weather proof |
Power Input | AC110V 60HZ / AC220V 50HZ, 10% more or less |
Power Consumption | Max.1200w/sqm Aver. 400w/sqm |
Working Temp. | -30 Celsius ~ +50 Celsius |
Working Humi. | 10% ~ 90% |
Maintenance | Rear access, replace fault components |
Signal Input | AV, S-Video, VGA, DVI, HDMI, SDI, DP (use Video Processor) |
Controlling Distance | CATE 5 < 100 mts; SMF < 10 KM; 3G, 4G controlling no distance limitation |
MTBF | > 5000 Hours |
LED Life Span | 100,000 Hours |
